FLIGHT CONTROLLER
H7 WINGCORE
The H7 WingCore is a fully NDAA-compliant dual-use flight controller for fixed-wing and VTOL drones.
100 % NDAA-COMPLIANT
The first release from Orqa’s upcoming fixed-wing ecosystem is fully NDAA-compliant.
MADE IN EU
Designed, manufactured, and assembled in Europe for complete supply chain sovereignty.
DUAL USE BY DESIGN
Featuring a MCU with the power to handle all common flight controller firmware including iNav, ArduPilot, and PX4, and enough servo outputs to manage even the most complex fixed wing platforms, the H7 WingCore is equally capable in both defense and enterprise roles.
weight
36.6 G
dimensions
54 x 39 x 17 mm
Mounting
30.5 x 30.5 mm
BEC
5V/8A, 6/7.2V/10A
Power Supply
11.1VDC - 44.4VDC (3 - 12s LiIon)
Buzzer
On-Board Integrated
Current Sensor
160A On-Board
Motor Outputs
4x (PWM, Dshot, CAN bus)
MCU
STM32H743
BAROMETER
DPS310
IMU
Twin (orthogonal) ICM-42688
OSD
Orqa’s custom NDAA-Compliant OSD (Text+Graphics)
FC Software
iNav, ArduPilot, PX4
Telemetry
SIK Radio
Camera Inputs
Twin analog switchable inputs
Interfaces
UART, GPIO, ADC, PWM, i2c CAN bus, USB-C
Learn More
If you're looking for a dual-use, fully NDAA-compliant flight controller, you just found it. Get in touch to discuss your exact operational requirements.
